AHB2 - Lab Report - Amirm, Audio Science Review
AHB2 - "Breaks New Ground ... Gets My Strongest Recommendation"
"The AHB2 easily outperforms the DIY Hypex NC400 I had tested before which used to be the best amp I had tested."
THD+N
"Looks far cleaner than anything I have tested before."
"Intermodulation distortion versus power level shows the same story of clean power."
No Rise in Out-of-Band Noise
"Usually when we test switching amplifiers we see all kind of "interesting" things in their outputs above hearing range. The AHB2 is a classic configuration albeit, with a switching power supply so all is well and clean here."
Signal to Noise Ratio
(22.5 kHz BW) at Max Power
- Ch1: 130.286 dB
- Ch2: 130.180 dB
Frequency Response
"Down 0.3 dB at 20 kHz. -3 dB down at 200 kHz!!"
"Since this is not a switching amplifier, there is no filter there - allowing the bandwidth to go to 200 kHz and beyond."
Stereo Power into 4 Ohms
"We have 185 watts of power at incredibly low distortion of 0.00016%, besting the company specifications."
Bridged Mono Power into 4 Ohms
"500 watts into 4 ohm! Stunning 0.00026% distortion at 500 watts!!"
Low-Power 5W THD Test
"As usual, I start with my 5 watt output test using 4 ohm load... I hope your jaw is on the floor just like mine was when I saw this picture emerge!"
"113 dB THD+N [at 5 W] in a power amplifier? Are you kidding me?"
"Look at the harmonic distortion. The worst case spike is below -130 dB! This is insanely good."
"Of course this type of SINAD (signal and noise ratio) crowns the Benchmark AHB2 as the best I have ever tested."
Noise and THD Measured Separately
"Separating the noise from THD, we see that it is noise that we are measuring as THD+N, rather than distortion. Noise dominates (more benign than distortion)."
Noise Relative to 5W
- Ch1: -112.964 dB
- Ch2: -112.550 dB
THD Only (no noise) at 5W
- Ch1: -122.337 dB
- Ch2: -120.982 dB
Protection System
"There are a set of LEDs that show the status of the amplifier. They are driven by an FPGA (field programmable digital logic) that monitors all aspects of the amplifier and shuts down the unit if stressed. It did so very quickly and efficiently in my testing. Usually this is done with purely analog or maybe a small microprocessor. As such, the coverage of scenarios that could damage the amplifier is much less complete than using the approach Benchmark is using in AHB2."
"Bridged mode using same 4 ohm load ... you get 500 watts of stunningly clean power. Protection circuits shut the unit down after that, so it is quite safe to try. With a THD essentially matching the non-bridged mode, there is no reason to be afraid of trying this."
"... the FPGA protection mode kicks in and essentially shuts the amplifier down past the limit. You get absolutely distortion-less and noiseless performance until there is no more."
Stereo/Mono Switch
"There is a switch for selecting stereo or mono bridged output. The latter quadruples the amount of power available."
Power Dissipation
"In use the AHB2 stays very cool for a power amplifier when it is idling, outputting little power which was a nice surprise."
Certifications
"Being a proper company of course the AHB2 comes with full set of regulatory/safety/emissions certifications which is super important with power amplifiers given the high voltages and currents running around in them."
Conclusions
"It goes without saying that the Benchmark AHB2 breaks new ground with respect to performance of power amplifiers."
"Using it, you can be assured that any distortion that you hear is from other sources (speaker, source, content, etc.). This is what I look for in high-end audio: absolutely the best performance so no second guessing is involved. You buy once, and you are happy forever!"
"All of this comes from a company that is a model of transparency with proper and accurate measurements of their products on their site. And importantly, volunteering to have that data shown to be correct by independent sources such as us."
"Needless to say, the Benchmark AHB2 gets my strongest recommendation."
- Amir Majidimehr (@amirm), AudioScienceReview.com
Read the entire review at AudioScienceReview.com →
Also in Reviews
AHB2 Review - Constantine Soo, Dagogo
"The AHB2 bridgeable stereo amplifier ... was the topic of a recent discussion between American electrostatic panel speaker manufacturer Sound Lab’s president, Dr. Roger West, and me."
"In our discussion, he related his highly positive experience in driving even his largest, $55k Majestic 945 panels with the $7,000 pair of Benchmark Media AHB2 monoblocks, along with the $3,050 LA4 Preamplifier and factory XLR cables."
"Dr. West described the AHB2 as a class AB design using “feed-forward distortion reduction [thus removing] any possibility of pushing the margin of safety of a standard feedback loop, used in most amplifiers, into an unstable oscillatory mode.”"
"He further shared with me that “this is of most concern on powerful musical transients. The distortion of the amplifier in the balanced mode is astonishingly low even at just below the clipping level of 380 watts.”"
"The prospect of the AHB2’s specified distortion level of 0.00015% or lower when at full volume is comical at first glance, but upon actual audition the impact of the achievement is very audible from medium-high listening levels and upward."
"It was unlike any other sub-$20,000 amplifier I have auditioned."
"My audition of the Benchmark Media AHB2 amplifiers underscores the reason Dr. West is so taken by it, and confirms the design is best described as a watershed moment in the high-end audio industry."
- Constantine Soo, Dagogo
DAC3 Review - Jerry Del Colliano
"Benchmark is a stalwart brand in pro audio, but has carved out a very respectable niche in the audiophile world with their diminutive but powerful components."
"The audiophile world sometimes looks to the professional audio world for enlightenment, especially on the digital side of things, and Benchmark Media is one of the companies that we put high on a pedestal."
"They are hardcore digital engineers freezing their asses off in upstate New York as they come up with some pretty innovative ways to get your varied digital sources sounding as much like the master tape as possible. Thank you for your service, gentlemen."
"If you really want to hear what your music sounds like in today’s streaming-driven world, this might just be the DAC that you need to test out."
- Jerry Del Colliano, Future Audiophile
DAC3 & AHB2 - System Review, Trevor Butler, The-Ear.net
"I began with the DAC3 HGC and AHB2 powering the glorious Morel Avyra 633 three-way floorstanders."
"This pairing created a full-bodied sound which brought the recording to life."
"Notable from the off was the bass from the DAC3 HGC and AHB2."
"Wow! It was deep, tight and conveyed a real feeling that the electronics were in charge of the transducers."
"Involuntary foot-tapping confirmed the timing ability and the overall presentation was spot-on, the Benchmark electronics created a fluent sound across a vivid soundstage; performers evident both tonally and spatially in an easy-to-believe presentation that brought the performance close."
"The Benchmark’s ability to retrieve deep-down detail and display it so well across the soundstage, with accurate positioning and convincing layering, made for a glorious re-creation of the recordings."
"To my mind the AHB2 is an amplifier with no obvious characteristics of its own: the level of transparency is sublime."
"Above all, the improved transient response performance stood out in a presentation that was not only lively but incredibly fast and revealing. The attack and decay displayed was awesome and not something I expect at this price point."
"The Benchmark DAC3 HGC and AHB2 are cracking products, sonically superior to a lot that’s available and well priced."
"They are superbly designed and built to an extremely high standard."
- Trevor Butler, the-ear.net
